For identifying escape routes in hazardous areas of zones 2 and 22.
Housing: Diecast aluminium, natural finish, gear set located inside the housing, wired ready for connection.
Cover: Polycarbonate opalescent white, (W), foamed silicone gasket. (Pictograms – if required – to be ordered separately, see accessories).
Connection terminal: 3 or 4 poles, clamping range max. 2,5 mm².
Cable entries: 1 cable gland M20×1,5 on the front side.
Mounting: Mounting sheet on the rear side.
More information please refer to below catalog:
SCHUCH Compact LED Emergency and Escape Sign Light Fitting for Ex-Zones 2&22 Series nD8611… .pdf
